Drum Filters for Aquaculture Fish Farms and Zoos

Drum Filters in Land Based Fish Farms

Drum Filters for aquaculture farms are mechanical units which materialize an efficient, robust and reliable solution in the process of solid and organic matter separation and filtration. These automatic self cleaning microscreen filters are able to handle a wide range of flow rate and backwash, utilizing micron rates from 10μm up to 10000μm. They are designed for high performance filtration in land based aquaculture water treatment systems such as salmon farms.

Design and manufacturing of Drum Filters for aquaculture farms, inside the factory.
Inhouse design and manufacturing of Drum Filters for aquaculture farms specifically designed for land based salmon farming.

Types of Drum Filters

The Micro Drum Filters are available with different configurations.

  • Available in 7 different drum diameters: 0.5 m -2.2 m OR 1.64 ft to 7.21 ft.
  • Available Filtration Area: 0.7 m²–21 m² or 7.53 ft² to 226 ft².
  • Available in two material types: All pastic tanks by Polypropylene (PP) or Titanium / Stainless Steel / Super Duplex Frame.

Advantages of Drum filters in Water Treatment

  • Filtration degree from 10.000 down to 10 micron.
  • Wide range of flow rates: 1m³/h – 4000 m³/h or 4.4 gpm – 17611 gpm.
  • Filtration without flow interruption.
  • Automatic Backwashing with means of both Pressure Difference and Timer.
  • Multiple material, tank type and frame type fabrication and design options.
  • Easy and hassle free maintenance.
  • Large Filtration area with 75% of Submerged Drum options.
  • Available with ATEX certificate requirements.
  • Mechanical Self Cleaning Filters
  • Drum Filters are able to operate in water with high salt concentration, providing corrosion resistance in particularly chloride stress conditions and chloride pitting corrosion.

Application in Salmon Farming RAS & Land Based Aquaculture

The MAT-KULING Drum Filters are specifically designed for land based aquaculture fish farms, salmon farms, hatcheries and other fish farming applications. They are available in stainless steel 304,316, Duplex SS, Super Duplex SS and Polypropylene in order to be able to treat both salt and fresh water fish farms.

Application in salt water closed circuit fish farm.
Application in salt water closed circuit fish farm.

Drum Filters Operation & Backwash Process in 6 Steps

Operation and Backwash Process of Drum Filters
Operation and Backwash Process of Drum Filters
  1. Untreated water enters the drum and is filtered through the screens before passing back to the system.
  2. Driving Force (Sieving) = The difference in water level inside/outside the drum.
  3. Solids are trapped and lifted to the backwash area by the rotational movement of the drum.
  4. Drum rotation can be intermittent or continuous depending on the type of control set by the operator.
  5. Backwash water is sprayed via nozzles from the outside onto and through the filter screens.
  6. Rejected materials are washed out of the filter screen into the collection tray and discarded from the filter using gravity.
Download Equipment Brochure
Drum Filters in Industrial Water Treatment
View Drum Filters in Industrial Water Treatment

Drum Filters - SPECIFICATIONS

DRUM FILTER DRF - 25DRF - 50DRF - 100DRF - 200DRF - 400DRF - 800
SUMP WITH SPLASH COVER LIDLength
[mm]
102112401240194032003900
Width
[mm]
114011401350135013501800
Height
[mm]
9439431500150015002000
Drum diameter
[mm]
5005001000100010001500
Drum lenght
[mm]
380740740148029603700
Drain Diameter
[mm]
Ø20Ø20Ø20Ø32Ø32Ø50
Drain Qty.
pcs
111111
Drain Level
[mm]
160160160160160160
Sump MaterialPPPPPPPPPPPP
INLETInlet Diameter
[mm]
Ø110Ø125Ø160Ø225Ø280Ø355
Inlet Qty.
pcs
111111
Inlet Level
[mm]
408408820820820850
OUTLETOutlet Diameter
[mm]
Ø110Ø125Ø160Ø225Ø280Ø355
Outlet Qty.
pcs
111111
Outlet Level
[mm]
225225225500500500
BACKWASH
SYSTEM
Waste Duct Outlet Diameter
[mm]
Ø50Ø50Ø50Ø63Ø63Ø75
Waste Duct Outlet Qty.
pcs
111111
Backwash Pump
material
AISI 316AISI 316AISI 316AISI 316AISI 316AISI 316
Backwash Pump
[kw]
1,101,101,10233,5
Nozzle Qty. (110°)
pcs
666122226
Total Nozzle Water Flow
[m³/hr]
1,441,441,442,885,286
Backwash line connection
[mm]
Ø32Ø32Ø32Ø32Ø40Ø40
Backwash numbers vs Conventional Drum Fiilters
%
-70%-70%-70%-70%-70%-70%
MESHFilter Surface
[m2]
0,451,102,304,609,2017,9
Mesh Size Range
[micron]
10-10010-10010-10010-10010-10010-100
Mesh MaterialPP & 314 & 316 SSPP & 314 & 316 SSPP & 314 & 316 SSPP & 314 & 316 SSPP & 314 & 316 SSPP & 314 & 316 SS
ELECTRICAL
PANEL
Electrical Control PanelStandardStandardStandardStandardStandardStandard
Electrical Panel Supply3Ph~400V 50Hz3Ph~400V 50Hz3Ph~400V 50Hz3Ph~400V 50Hz3Ph~400V 50Hz3Ph~400V 50Hz
Electrical Panel Power
[kw]
1,301,301,302,203,203,6
Electrical Panel Current
[A]
3.1A3.1A3.1A4.85A6.8A7,7A
Electrical Panel IPIP65IP65IP65IP65IP65IP65
Drive Motor DC/24V
[watt]
909090909090
MAX FLOW RATES (100 µ mesh)
[m³/h] 5 ppm TSS
36901803607201440
HEAD LOSSAverage
[mmwc]
210210210220220250
WEIGHTDry
[kg]
105120180225320450
Wet
[kg]
455545930167526204980
CONTROL BOARDAutomated PLC-HMI system
Colored HMI screen size (")
444477
Standart FunctionsOperation mode selections ( continous slow rotation on filter mode , no rotation on filter mode ) Rotation speed settings , Sequance log and records for water consumption and frequency , overflow alarm , mesh screen rupture alarm , service alarm , SMART WASH LOGIC ( autonomous learning and auto selection for optimum washing duration and rotation speeds.
DRUM FILTERDRF - 25DRF - 50DRF - 100DRF - 200DRF - 400DRF - 800
Splash Cover Lidoptionaloptionaloptionaloptionaloptionaloptional
Backwash Pumpoptionaloptionaloptionaloptionaloptionaloptional
* MAT-KULING AS™ preserves the right to update anytime the listed prices (if any). Every effort has been made so that the above specs are accurate. However please contact our Sales Department for up to date technical data, electrical specs according to your regional requirements and current Ex-Works pricelist. The listed prices are for the basic equipment and do not include any optional components.
