Moving Bed Biofilter Reactors (MBBR)

Moving Bed Biofilter Reactors (MBBR)
MAT MBBR filters are made of PP plastic and they are designed to create proper media swell, allowing maximum bacteria oxygenation with minimal backwash requirements. Filled with floating biomedia will provide optimum biological filtration support . MAT MBBR are equipped with venturis & come fully installed and hydrotested.


The MBBRs (Moving Bed Biofilter Reactors) are biological filters, fabricated to provide biological filtration and maximize oxygen concentration while enabling organic load degradation. MBBR biotowers, are made of PP, resistant to osmosis and ozone gas. MBBR range covers the treatment needs for Biomass load from 10 up to 850kg per bio-tower, utilizing low water volume and small footprint. The non-treated water swell is continuously mixed with air/oxygen in the biotower, while the organic load is degraded biologically by microorganisms. This bio-film layer is formed on and in suspended polyethylene floating media.

Our Moving Bed Biofilter Reactor is a tested and proven biological filtration solution that allows high oxygen concentration and excellent TAN removal at the smallest possible footprint.

The MBBR systems are applicable to any biologically charged water volume and it is commonly used to fresh and marine RAS farms and hatcheries.


The Moving Bed Biofilter Reactor retains the organically charged water by creating a vortex, to evenly move the bio media into the highly oxygen saturated contact chamber. This retention allows the microorganisms to biologically absorb the nutrients off the water at a higher level than a traditional trickle filter.

The PE bio-balls provide on their surface the optimum environment for the biofilm layer growth and activity. The activity of the micro-organisms biofilm conversion of the organic load to NO3 is enhanced by continuous air/oxygen infusion into the moving bed reservoir. MAT-KULING integrated MBBR design optimizes the air mixing process through high pressure air injection and fine air bubble subsequent formulation.


  • Advanced Reactor design, Robust and Proper for saline and fresh water
  • Improved biological reactor for aquaculture facilities
  • Long Lasting Polyethylene moving bed media
  • Better biological filtration than trickle filters
  • Ease in operation & maintenance

Moving Bed Biofilter Reactors (MBBR) - SPECIFICATIONS

MODELDiameter [mm]Height [mm]Basic Unit Total Electric Consumption [kWh/hr]Supply Voltage 50Hz [V]Water
Level [mm]
Size [mm]
Level [mm]
Size [mm]
Max Flow [m³/h]Air Flow Rate [m³/h]Blower ModelBLOWER Driver ModelTAN Removal Rate with BM-1000 [gr TAN/day]TAN Removal Rate with BM-4500 [gr TAN/day]Max BM-1000 media [m³]Max BM-4500 media [m³]Body MaterialOVERFLOW SWITCHBIOMEDIA
MAT MBBR-50050013730.373~400/230117290872110154.710DL-MDEP66-0022 T31024240.170.15FOOD GRADE PPOPTONALOPTIONAL
MAT MBBR-75075017760.553~400/23015181401218160552015DH-MDEP66-0022 T329712330.490.42FOOD GRADE PPOPTONALOPTIONAL
MAT MBBR-1000100019780.553~400/23015852251285250802315DH-MDEP66-0022 T358724410.980.84FOOD GRADE PPOPTONALOPTIONAL
MAT MBBR-1250125022231.13~400/2301845250154528012044R30MDEP66-0022 T3103142871.721.47FOOD GRADE PPOPTONALOPTIONAL
MAT MBBR-1500150027752.23~400/2302259280195931522044K04TDEP66-0022 T3185477063.092.65FOOD GRADE PPOPTONALOPTIONAL
MAT MBBR-2000200028502.23~400/2302179315187935528095K04TDEP66-0022 T33384140705.644.83FOOD GRADE PPOPTONALOPTIONAL
* MAT FILTRATION TECHNOLOGIES™ preserves the right to update anytime the listed prices (if any). Every effort has been made so that the above specs are accurate. However please contact our Sales Department for up to date technical data, electrical specs according to your regional requirements and current Ex-Works pricelist. The listed prices are for the basic equipment and do not include any optional components.
