Radial Flow Settler (RFS)

Radial flow settler (rfs)

Radial Flow Settler (RFS)

The Radial Flow Settler (RFS) is highly cost effective in reducing solids loading in a system and operates passively, requiring no additional energy. This low-maintenance equipment is designed for routine cleaning only, with no need for extra servicing or repairs. Available in various sizes to accommodate different flow requirements, the RFS is also optimized for containerized shipping, making it accessible for worldwide use.

Radial flow settler (rfs)

The MAT-KULING Radial Flow Settler (RFS) is an efficient solution for removing particulates from effluent water in various industrial applications. The system works by directing the water into the RFS Liquid Inlet, where it flows upward through the adjustable Standpipe Assembly and down through the Stilling Well. During this process, solid particulates naturally settle to the cone bottom and are easily removed via the Solids Outlet. The filtered water then rises over a V-Notch Weir into the Launder and exits through the Liquid Outlet, ensuring cleaner and safer water discharge.

ALL EQUIPMENT CATALOG

Specifications

Model	RFS-315-45	RFS-315-60	RFS-500-45	RFS-500-60	RFS-610-45	RFS-610-60	RFS-750-45	RFS-750-60	RFS-1100-45	RFS-1100-60	RFS-1600-45	RFS-1600-60	RFS-1900-45	RFS-1900-60	RFS-2200-45	RFS-2200-60	RFS-2500-45	RFS-2500-60	RFS-2800-45	RFS-2800-60	RFS-3000-45	RFS-3000-60	RFS-3400-45	RFS-3400-60	RFS-4300-45	RFS-4300-60	RFS-5500-45	RFS-5500-60
Diameter (mm)	315	315	500	500	610	610	750	750	1100	1100	1600	1600	1900	1900	2200	2200	2500	2500	2800	2800	3000	3000	3400	3400	4300	4300	5500	5500
Max. Flow (@0.003 m/s) (m3/h)	0.78	0.78	1.97	1.97	2.93	2.93	4.42	4.42	9.68	9.68	20.34	20.34	28.65	28.65	38.37	38.37	49.62	49.62	62.31	62.31	70.87	70.87	91.13	91.13	146.49	146.49	239.84	239.84
Average. Flow (@0.0015 m/s) (m3/h)	0.39	0.39	0.98	0.98	1.46	1.46	2.21	2.21	4.84	4.84	10.17	10.17	14.32	14.32	19.18	19.18	24.81	24.81	31.15	31.15	35.43	35.43	45.56	45.56	73.24	73.24	119.92	119.92
Stilling Well Diameter (mm)	80	80	130	130	160	160	200	200	260	260	400	400	480	480	560	560	630	630	700	700	800	800	900	900	1100	1100	1400	1400
Stilling Well Length (mm)	350	350	370	370	390	390	410	410	440	440	500	500	550	550	580	580	620	620	650	650	700	700	730	730	850	850	1000	1000
Launder Width (mm)	90	90	90	90	110	110	110	110	110	110	150	150	180	180	220	220	220	220	240	240	290	290	300	300	360	360	440	440
Launder Depth (mm)	300	300	300	300	300	300	300	300	300	300	300	300	300	300	300	300	400	400	400	400	500	500	600	600	700	700	800	800
Net Settling Area (m2)	0.07	0.07	0.18	0.18	0.27	0.27	0.41	0.41	0.89	0.89	1.88	1.88	2.65	2.65	3.55	3.55	4.59	4.59	5.76	5.76	6.56	6.56	8.43	8.43	13.56	13.56	22.2	22.2
Max. OD. (mm)	600	600	700	700	900	900	1000	1000	1300	1300	1900	1900	2200	2200	2500	2500	2800	2800	3200	3200	3500	3500	3800	3800	4800	4800	6000	6000
Inlet Connection Size (mm)	32	32	40	40	50	50	63	63	75	75	90	90	110	110	125	125	140	140	160	160	200	200	200	200	315	315	355	355
Outlet Connection Size (mm)	40	40	50	50	63	63	75	75	90	90	110	110	125	125	140	140	160	160	250	250	280	280	315	315	355	355	400	400
Sludge Connection Size (mm)	32	32	40	40	50	50	50	50	63	63	63	63	75	75	75	75	90	90	90	90	110	110	110	110	125	125	140	140
Cone Angle°	45	60	45	60	45	60	45	60	45	60	45	60	45	60	45	60	45	60	45	60	45	60	45	45	60	45	60	60
Max. Height (mm)	1300	1550	1400	1700	1470	1767	1552	1916	1817	2279	2543	3137	2708	3534	2939	3699	2972	4029	3137	4359	3269	4623	3468	4953	3798	5614	4128	6274

* MAT-KULING AS™ preserves the right to update anytime the listed prices (if any). Every effort has been made so that the above specs are accurate. However please contact our Sales Department for up to date technical data, electrical specs according to your regional requirements and current Ex-Works pricelist. The listed prices are for the basic equipment and do not include any optional components.
